LuxPower SNA-US 6000 | Eco Hybrid Split-Phase Inverter (120/240V)
$2,395.54
6kW hybrid inverter with split-phase 120/240V output, 8kW PV input, and lithium/lead-acid battery support. Generator-ready, parallel-capable, and packed with safety features like AFCI and RSD. Perfect for off-grid homes and backup systems.
Compact Powerhouse for Off-Grid and Backup Freedom
The SNA-US 6000 is a 6kW hybrid inverter engineered for residential off-grid systems and resilient backup setups. It delivers true split-phase 120/240V output, handles up to 8kW of solar, and supports up to 16 units in parallel — making it ideal for everything from cabins and tiny homes to whole-house battery systems.
With built-in breakers, AFCI, generator support, and rapid shutdown compliance, this unit packs premium features in a compact, lightweight chassis.
✅ Highlights
- 6,000W continuous power output
- True 120/240V split-phase output
- 8kW PV input with dual MPPTs
- Seamless <15ms transfer time (UPS grade)
- Parallel-ready: Supports up to 16 inverters
- Dedicated generator / smart load / AC-coupling port
- Integrated protection: AFCI, RSD, surge, and breakers
- Works with lithium or lead-acid 48V batteries
⚙️ Technical Specs
| Category | Details |
|---|---|
| Model | SNA-US 6000 |
| Max PV Array Power | 8,000W (4,000W + 4,000W) |
| Rated PV Input Voltage | 320V |
| MPPTs / Strings | 2 MPPTs / 2 strings |
| MPPT Voltage Range | 120V–385V |
| Battery Voltage | 48V (38.4–60V range) |
| Max Charge/Discharge | 6,000W (125A/140A) |
| AC Output | 120/240V split-phase, 50/60Hz |
| Surge Power | 7370W for 2s |
| Transfer Time | <15ms (single) / <30ms (parallel) |
| Efficiency (PV to AC) | 93.0% |
| Max MPPT Efficiency | 99.9% |
🛡️ Protection & Compliance
- AFCI + PV Arc Fault Detection
- Rapid shutdown (RSD) ready
- Reverse polarity + short-circuit protection
- Type III AC surge protection
- Built-in DC, AC, battery & generator breakers
- Certified: CSA C22.2, UL 1741
📏 Physical Specs
| Parameter | Value |
|---|---|
| Dimensions | 450 × 650 × 150 mm (17.7 × 25.6 × 5.9 in) |
| Weight | 24 kg (53 lbs) |
| Cooling | Smart convection |
| Protection Rating | IP20 |
| Operating Temp | -15°C to 60°C |
| Altitude | Up to 2000m |
| Noise | <50 dB |
| Interface | LCD+LED screen, RS485 / Wi-Fi / CAN |
| Warranty | 2 years |
