MC4 Solar PV Connector Pair – Male & Female with Pins (IP67 Rated)

Standard MC4 Connectors for Secure, High-Current Solar Connections

This 1-pair MC4 Solar PV Connector Set includes one male and one female connector with tin-plated copper contacts. Built for solar applications up to 1000V (TUV) / 600V (UL) and 30A, these connectors ensure a stable, weatherproof connection for solar panels, inverters, and combiner boxes.

Compatible with 2.5mm²–6mm² (AWG #14–10) cable, the connectors feature snap-in self-locking tabs, IP67 protection, and UL94-V0 flame retardant housing. Field-installable and certified by TUV for global compatibility.

For DIY solar kits, these connectors are the go-to solution for safe and secure panel wiring. Perfect for camper vans, cabins, RVs, or backyard energy setups — no soldering or special tools required.

✅ Key Features

• Includes 1 male + 1 female MC4 connector with pins
• Rated for 30A, 1000V TUV / 600V UL
• Tin-plated copper contacts for corrosion resistance
• PPO/TPE insulation body, flame-retardant (UL94-V0)
• Self-locking snap-in design
• IP67 waterproof/dustproof protection
• Works with 2.5mm² / 4mm² / 6mm² cables (AWG 14/12/10)
• Certified: TUV compliant

🔧 Technical Specifications
