Schneider Conext MPPT 100 600 Solar Charge Controller – 6kW | 100A | 600V DC
$2,545.00
600V MPPT charge controller with 100A output and 6000W capacity. Compatible with 24V/48V batteries and lithium systems. Supports large PV arrays and rapid shutdown. Built for off-grid and hybrid systems. Schneider Insight-ready with app control.
High-Voltage, High-Efficiency MPPT for Large-Scale DC-Coupled Solar Systems
The Schneider Electric Conext MPPT 100 600 is a high-performance, 600V DC MPPT charge controllerengineered for large PV arrays and DC-coupled storage systems. It provides 100A charging current and supports oversized PV arrays of 7kW or more, with a fast-sweep MPPT algorithm that maximizes solar harvest — even in partially shaded conditions.
Perfect for hybrid energy systems and grid-tied or off-grid applications, the MPPT 100 600 is compatible with lithium, AGM, GEL, and flooded batteries, and pairs seamlessly with Schneider’s XW Pro, XW+, and SW series inverters. Built for rapid deployment with minimal wiring and no need for a combiner box, it’s ideal for installers seeking fast, scalable solutions.
✅ Key Features
- Rated for 6000W output at 48V, 100A charge current
- 600V DC input for longer string lengths and reduced wire size
- Wide MPPT operating range: 195–510V DC
- Compatible with 24V and 48V battery banks
- Recharges dead batteries from solar during outages
- Supports oversized PV arrays (7kW+)
- Rapid shutdown ready with Disconnect RS accessory
- Integrated system control via Insight app & Gateway
🔧 Technical Specifications
| Parameter | Value |
|---|---|
| Nominal Battery Voltage | 24V / 48V DC |
| PV Operating Voltage Range | 195 – 550 V DC |
| MPPT Voltage Range | 195 – 510 V DC |
| Max PV Open Circuit Voltage | 600 V DC |
| Max PV Short-Circuit Current | 35A |
| Max Output Charging Current | 100A |
| Max Output Power | 6000W @ 48V |
| Supported Battery Types | Flooded, GEL, AGM, Lithium-ion, Custom |
| Regulation Method | 3-stage or 2-stage with manual equalization |
| Max Conversion Efficiency | 95% (48V) / 92% (24V) |
| Night Power Consumption | < 1W |
| Communication | CAN, RS485, Insight Gateway compatible |
| Auxiliary Output | Dry contact up to 60V DC / 30V AC, 8A |
| Protection Rating | IP20 (indoor) |
| Enclosure Material | Aluminum chassis, ventilated |
| Operating Temperature | -20°C to +65°C (derates > 40°C) |
| Storage Temperature | -40°C to +85°C |
| Weight | 13.5 kg (29.8 lbs) |
| Dimensions (H x W x D) | 76 × 22 × 22 cm |
| Certifications | UL1741, CSA 107.1, CE, FCC, IC |
