SMA CORE1 DC Surge Protection Kit | Type 1+2 OVP (MOV-Based)
$254.96
SMA CORE1 DC SPD Kit (Type 1+2) safeguards your inverter’s DC inputs from lightning and transient surges. MOV-based and fully replaceable, it’s a must-have for long-term protection in grid-tied or off-grid solar systems.
Serious protection for your PV strings.
This Type 1+2 Surge Protection Kit from SMA is purpose-built for the DC side of CORE1 inverters. Featuring Metal Oxide Varistor (MOV) technology, it shields your system from both direct lightning strikes and grid-switching surges—right where damage often starts.
Smart, field-replaceable design.
Easy to install and fully serviceable, this SPD module snaps directly into your CORE1 inverter’s DC surge slots. Whether you’re installing a new system or retrofitting for higher resilience, it delivers reliable protection without interrupting performance.
🔧 Technical Specifications – SMA CORE1 DC SPD Kit (Type 1+2)
| Attribute | Details |
|---|---|
| Product Type | Surge Protection Device (SPD) Module |
| Surge Class | Type 1+2 OVP (DC Side Protection) |
| Technology | MOV (Metal Oxide Varistor) |
| Application | For SMA CORE1 inverter (DC input side) |
| Replaceable | Yes – Field-replaceable module |
| Installation | Slides directly into built-in SPD slots |
| Certifications | IEC/EN 61643-11, UL listed |
| Weight | 4.00 lbs (1.81 kg) |
| Dimensions | 8.0 × 18.0 × 5.0 cm (W × H × D) |
| Use Case | Lightning protection, transient surge suppression |
📦 What’s Included:
• 1x Type 1+2 SPD module for DC surge protection
• Compatible with SMA CORE1 inverter SPD DC slots
